Wavelength: 635nm,650nm,658nm
Output power: 1mW,5mW,10mW,20mW,30mW,50mW,100mW
Beam divergence: 0.1mrad ~ 0.6mrad
Line thickness: Less then 2mm at 5m
Fan angle: 10°～120°
Laser line accuracy: <30”(at 5m)
Operating Voltage: DC3V-5V
Port: TTL
Specifications:
Wavelength: 635nm,650nm,658nm
Output power: 1mW,5mW,10mW,20mW,30mW,50mW,100mW
Beam divergence: 0.1mrad ~ 0.6mrad
Line thickness: Less then 2mm at 5m
Fan angle: 10°～120°
Laser line accuracy: <30”(at 5m)
Operating Voltage: DC3V-5V
Port: TTL
Operating Temperature: -10℃～70℃
Storage Temperature: -30℃～80℃
Dimensions: Φ12×45mm, Φ16×60mm
MTTF: 10000 hours
Characteristics:
High-quality laser diode,optical glass lens, driver circuit and housing
Better line quality
High reliability, high stability, long life,low price
Applications:
Machine vision
Industrial inspection
Industrial marking devices
3D contour mapping
Positioning & visualization
Biomedical
High-end alignment
Laser targeting devices and so on..
